New Old Stock

Motorola XPR 3300e Portable Two-Way Radio

$395.00

50 units left in UHF (403–512 MHz)

New Old Stock Motorola MOTOTRBO XPR 3300e. Compact 16-channel, non-display two-way radio with analog and DMR digital communications. Optional features and supplied equipment are confirmed before invoicing.

Band

Restored to brand-new OEM specification

Bench-tested for transmit, receive & battery

Genuine parts used in every refurbishment

Request now — pay only through your invoice

Specifications

Band: UHF 403–512 MHz / VHF 136–174 MHz
Channels / controls: 16 channels; no display or keypad
Transmit power: UHF 1 W / 4 W; VHF 1 W / 5 W
Modes: Analog FM and DMR digital; ETSI TS 102 361-1, -2, -3
Channel spacing: 12.5 / 25 kHz; 25 kHz not available in the USA
Dimensions, standard battery: 122 × 56 × 36 mm (4.8 × 2.2 × 1.4 in)
Weight, standard battery: 264 g (9 oz)
Dimensions / weight, high-capacity battery: 122 × 56 × 42 mm; 292 g (10 oz)
Power supply: 7.5 V nominal
Battery life, 2100 mAh standard: VHF digital / analog: 19.5 / 14 h; UHF: 18.5 / 14 h
Battery life, 3000 mAh high capacity: VHF digital / analog: 28.5 / 21 h; UHF: 27.5 / 21 h
Battery test conditions: Typical 5/5/90 duty cycle at maximum power, Wi-Fi and apps off; battery package and runtime vary
Digital modulation: 4FSK; 12.5 kHz voice and data
Frequency stability: ±0.5 ppm
Adjacent-channel power: 60 dB at 12.5 kHz; 70 dB at 25 kHz
Emissions: −36 dBm below 1 GHz; −30 dBm above 1 GHz
Analog / digital sensitivity: 0.16 μV at 12 dB SINAD / 0.14 μV at 5% BER
Receiver intermodulation / spurious rejection: 70 dB / 70 dB
Receiver selectivity: TIA603A 1T: 60/70 dB; TIA603D 2T: 45/70 dB at 12.5/25 kHz
Audio: AMBE+2 vocoder; 0.5 W rated output; 3% distortion; TIA603D response
Audio hum / noise: −40 dB at 12.5 kHz; −45 dB at 25 kHz
Audio spurious emissions: −57 dBm
Dust / water: IP67: 1 m immersion for 30 minutes
Operating / storage temperature: −30 to +60°C / −40 to +85°C; low-temperature battery required below −10°C
ESD / packaging: IEC 61000-4-2 Level 4 / MIL-STD 810D and E
Bluetooth (configuration dependent): 4.0, Class 2, 10 m; HSP, SPP, Motorola fast PTT; one audio accessory
Wi-Fi (configuration dependent): 802.11b/g/n; WPA, WPA2, WEP; up to 64 SSIDs
Optional features: Bluetooth, Wi-Fi, trunking and privacy depend on fitted options / licensing; not guaranteed
HazLoc: Only certified configurations with Motorola UL-approved battery; no HazLoc certification promised for this listing
FCC / IC: VHF AZ489FT7069 / 109U-89FT7069; UHF AZ489FT7068 / 109U-89FT7068
Warranty: One year from delivery, on every radio sold.
Returns: 30 days. The unit must still have its protective film and the original box.
